| Grade | Ni | Mn | P | C | S | Si | Cr | Mo | N | |
| 316 | min. | 10 | – | – | – | – | – | 16 | 2 | – |
| max. | 14 | 2 | 0.045 | 0.08 | 0.03 | 0.75 | 18 | 3 | 0.1 | |
| Grade | Tensile Strength (MPa) Minimum | Yield Strength 0.2% Proof (MPa) Minimum | Elongation (% in 50mm) Minimum | Hardness | |
| Rockwell B (HR B) Maximum | Brinell (HB) Maximum | ||||
| SS 316 Pipe | 515 | 205 | 40 | 95 | 217 |
Product name | industrial pipe |
ASTM | A53,A283,A106-A,A179,A214C,A192,A226,A315,A106,A178, |
GB | 16Mn20Cr,40Cr,35CrMo,45CrMo,10CrMo910,15MnV,09Mn2v,06A1NbCuN,16Mo,12CrMo,15CrMoG,12Cr1MoVG,Cr5Mo,1Gr13,2Cr13,1Cr17 |
JIS | G3452 G3457 G3456 G3461 G3454 G3455 |
DIN | DIN1626 DIN17175 DIN1629/4 DIN1629/3 |
Dimensions | OD10mm-930mm*WT1-180mm or customized |
Length: | 6-12M or as required |
Standard: | ASTM，AISI，JIS，GB， DIN，EN |
Surface treatment | Black/Peeling/Polishing/Machined |
Technique | Cold/Hot rolled, Cold-Drawn， or Hot Forged |
Heat Treatment | Annealed; Quenched; Tempered |
price terms | FOB,CRF,CIF,EXW all acceptable |
Delivery Detail | inventory About 3-5； custom-made 10-15；rding to order's quantity. |
Loading port | any port in China |
Packing | standard export packing (inside:water proof paper,outside:steel covered with strips and pallets) |
Payment Terms | T/T, L/C at sight,West Union,D/P,D/A,Paypal |
Kuaima steel has extensive industry experience, an expert staff, and state-of-the-art equipment.
